Ground pressure (standard track) is 5.8 psi. The machine delivers a breakout force of 5,300.1 lbf for the bucket and 5,000 lbf at the lift arm, with a maximum tractive effort of 9,873.6 lbf at 100% effective force. Cycle times include bucket rollback at 1.6 seconds, bucket rollout at 2.1 seconds, lift arm raise at 3.7 seconds, and lift arm lowering at 2.5 seconds. Travel speeds are 6.5 mph in stage 1 and 9.6 mph in stage 2. Overall length without the bucket is 106.6 inches, and with the bucket is 136.6 inches. Overall width without the bucket is 67.1 inches, with a large track width of 70.3 inches. The overall height to the top of ROPS is 83 inches. Bucket hinge pin height measures 125.5 inches, with a bucket rollback angle of 30° at both ground level and maximum height. The angle of departure is 30°, while the bucket dump height at maximum reach is 97.2 inches with a dump angle of 42°.

Operating weight is 8,095.4 lbs. Track width is 12.8 inches, with an optional width of 15.7 inches, and ground clearance is 9.1 inches. The length of track on the ground is 57.2 inches, and dump reach at maximum height is 39.2 inches. Hydraulic flow rate is 19.8 gal/min, with a maximum flow rate of 29.9 gal/min, and auxiliary relief pressure is 3,494.5 psi. The fuel tank capacity is 32.8 gallons (US). Tip load is 6,199.4 lbs, with a rated operating capacity of 3,099.7 lbs at 50% tip load and 2,169.4 lbs at 35% tip load.
